PANTHER T12
Home / Produits / Straight Body /

PANTHER T12

PANTHER T12

Carry heavy loads in variable working conditions.

Power

product.detail.Power

250 HP @ 2200 rpm
186 kW @ 2200 rpm
Payload

product.detail.Payload

25,000 lb
11.340 kg
Heaped Capacity

product.detail.Heaped Capacity

7.7 yd³
5.9 m³
product.detail.hero.contact

product.detail.values.headline

Get more done

Get more done

Productivity is key for this model. With a 35% speed increment, Prinoth strives to help its customers do more.

Be More Profitable

Be More Profitable

Panther Crawler Carriers continually provide unparalleled uptime and performance by virtue of the vehicles’ high quality components.

Made in North America

Made in North America

Prinoth crawler carriers are proudly designed, engineered and manufactured in Canada making them easily accessible to the entire North American market.

Playing in the sand!

Sand Hauling in Europe

product.detail.features.nav-headline

Panther models ranging from T6 to T14R fit on regular-sized transport decks which limits owners from having unnecessary special permits and extra costs.

Transport Width

PRINOTH collaborated with CAMSO (acquired by Michelin in 2019) to develop and manufacture patented tracks that provide optimized results for performance, traction, side hill grip and durability. This endless rubber track with embedded steel crosslinks provides longer track life and higher reliability.

Metal-embedded rubber track (MERT)

There are no daily maintenance needed with Panther vehicles which results in less downtime. The Prinoth patented-undercarriage has fewer moving parts for less corrosion spots, and the vehicles all have an automatic track tensioner which doesn’t have any greasing points.

Ease of maintenance

product.detail.technical-data.headline

product.detail.brochure.download

  • product.detail.Power

    250 HP @ 2200 rpm
    186 kW @ 2200 rpm

  • product.detail.Payload

    25,000 lb
    11.340 kg

  • product.detail.Heaped Capacity

    7.7 yd³
    5.9 m³

  • product.detail.Speed

    8.4 mph
    13,5 km/h

  • product.detail.Ground pressure

    3.50 psiproduct.detail. GP_T12_SB
    24,13 kPaproduct.detail. GP_T12_SB

  • product.detail.Maximum Gradeability Uphill/Downhill

    60%
    31,0°

  • product.detail.Maximum Gradeability Side hill

    40%
    21,8°

  • product.detail.Length

    240.4 in
    6.107 mm

  • product.detail.Shipping Width

    101.2 in
    2.570 mm

  • product.detail.Height

    114.9 in
    2.918 mm

  • product.detail.Standard Equipment

    product.detail.SE_T12_SB
    product.detail.SE_T12_SB

  • product.detail.Optional Equipment

    product.detail.OE_T12_SB
    product.detail.OE_T12_SB

Sustainability

Sustainability

For us, sustainability is more than a commitment — it's part of our purpose. We focus on being environmentally and socially responsible while enhancing performance and efficiency.
